11. Options and peripheral devices
11 - 2
11.1.1 Combinations of cable/connector sets
Refer to Servo Motor INSTRUCTION MANUAL (Vol.3) about options for
servo motor power, electromagnetic brake, and encoder.
Battery
(Servo amplifier attachment)
6)
CN1A
CN1B
CN3
CNP1
CNP2
CNP3
Servo
amplifier
CN1A
CN1B
CN2
CN3
7)
2)3)4)
Cap
(Servo amplifier attachment)
(Note 1)
Servo system
controller
Personal
computer
5)
1)
Servo
amplifier
2)3)4)
CN2
CN8
CN5
CN8
CN5
(Note 3)
(Note 2)
CN4 CN4
To 24 V DC power supply
for electromagnetic brake
Servo motor
Encoder
connector
Brake
connector
Power supply
connector
Liner servo motor
Liner encoder
Power supply connector
Direct drive motor
Encoder connector
To CN2
To CN2
The connection method changes
depending on INC/ABS system.
Refer to Liner Encoder INSTRUCTION MANUAL about options
for liner encoder.
Refer to DIRECT DRIVE MOTOR INSTRUCTION MANUAL
about options for direct drive motor power and encoder.
8) 8)
CN9
CN10
Safety logic unit
MR-J3-D05
Note 1. Connectors for 3.5 kW or less. For 5 kW or more, terminal blocks.
2. When not using the STO function, attach a short-circuit connecter ( 9) ) supplied with a servo amplifier.
