Appendix. B Board Layout Appendices
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] B-7
B.5 Serial port Board (FLGSR*)
Figure B-5 Serial port Board (FLGSR*) layout
Table B-5 Serial port Board (FLGSR*) connectors
Mark Number Name
(a) CN3440 Serial port
(b) CN4632 USB connector
(c) CN3504 System board I/F connector
(d) CN4630 USB harness connector
(a)
(b)
(c)
(d)
