3.20 ONLY ONE TEST 3 Tests and Diagnostics
3-42 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
Subtest 01 Pressed key display
When you execute this subtest, the keyboard layout is drawn on the display as
shown below. When any key is pressed, the corresponding key on the screen
changes to the key character that was pressed. Holding a key down enables the
auto-repeat function that causes the key’s display character to blink.
Press Del + Enter to end the test.
IF TEST OK, Press [Dell][Enter]key
