Appendices Appendix. B Board Layout
B-6 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
B.4 Parallel port Board (FLGCP*)
Figure B-4 Parallel port Board (FLGCP*) layout
Table B-4 Parallel port Board (FLGCP*) connectors
Mark Number Name
(a) CN4613 Parallel port
(b) CN4622 USB connector
(c) CN3503 System board I/F connector
(d) CN4620 USB harness connector
(a)
(b)
(c)
(d)
