4.23 Fluorescent Lamp 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-93
NOTE: Make sure there is no dust between the LCD panel and backlight unit. If any dust
is found, remove it with crepe tape or others which has no remaining of paste.
Figure 4-78 Replacing 15.0 Inch Sharp fluorescent lamp (XGA) (17)
(H) Backlight unit
(I) LCD panel
Guide
rib
Guide rib
Guide rib
Guide rib
M
ake sure
the
LCD panel is
installed in the guide rib
