1 Hardware Overview 1.7 DVD-ROM & CD-R/RW Drive
1-18 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
1.7 DVD-ROM & CD-R/RW Drive
The DVD-ROM & CD-R/RW drive accommodates either 12 cm (4.72-inch) or 8 cm (3.15-
inch) CD, CD-R/RW and DVD. It is a high-performance drive that reads DVD at maximum
8-speed, and reads CD at maximum 24-speed.
The DVD-ROM & CD-R/RW drive is shown in Figure 1-8. The specifications of the DVD-
ROM & CD-R/RW drive are described in Table 1-8 and 1-9.
Figure 1-8 DVD-ROM & CD-R/RW drive
Table 1-8 DVD-ROM & CD-R/RW drive dimensions
Items Standard
Maker
Panasonic
(G8CC0002J220)
TSST
(G8CC0002V220)
Dimensions
Width (mm)
128
Height (mm)
12.7
Depth (mm)
129.0
Weight (g)
180 ±10 179 ±15
