4 Replacement Procedures 4.17 Battery Latch
4-52 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
Installing the Battery latch
The following describes the procedure for installing the battery latch (See Figure 4-35, 4-36).
1. Set the spring to the battery lock L and install it on the base assembly.
2. Install the SB latch button from the bottom of the base assembly and snap their
projections to the battery lock L. When installing the button, make sure the triangle
mark on the back side is located in the indicated position. After installation, slide the
latch on the bottom of the base assembly to make sure it works properly.
