1 Hardware Overview 1.12 Batteries
1-30 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
1.12 Batteries
The PC has the following two batteries.
? Main battery
? Real time clock (RTC) battery
Table 1-15 lists the specifications for these two batteries.
Table 1-15 Battery specifications
Battery Name Capacity
Material Output
Voltage
G71C0003V910
G71C0003VA10
G71C0003VD10
G71C0003VE10
G71C0005H110
G71C0005H210
4,400mAh
G71C0004G510
G71C0004G610
4,700mAh
lithium ion
(6-cell)
G71C0003W210
Main battery
G71C0003W110
8,800mAh
lithium ion
(12-cell)
10.8V
Real time clock
(RTC) battery
GDM710000041 17mAh
Nickel metal
hydride
3.0V
1.12.1 Main Battery
The main battery is the primary power supply for the computer when the AC adapter is not
connected. In resume (instant recovery) mode, the main battery maintains the current status
of the computer.
