3 Tests and Diagnostics 3.2 Executing the Diagnostic Test
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 3-9
3.2.3 Heatrun test program
Heatrun test starts executing the same subtest as 3.24 RUNNING TEST.
For more details on this test, refer to the section 3.4.
