3.15 NDP Test 3 Tests and Diagnostics
3-32 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
3.15 NDP Test
To execute the NDP test, select 10 from the DIAGNOSTICS TEST MENU, press Enter and
follow the directions on the screen.
Subtest 01 NDP
This test checks the following functions of NDP:
? Control word
? Status word
? Bus
? Addition
? Multiplication
