3.27 Wireless LAN Test Program (Intel-made a/b/g) 3 Tests and Diagnostics

3-62 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)

3.27 Wireless LAN Test Program (Intel-made a/b/g)

This section describes how to perform the wireless LAN transmitting-receiving test (Intel-made

Calexico 802.11a/b/g). To execute the wireless LAN test, use the Diagnostics disk for wireless

LAN test. Finish the tests of the Main test program by selecting 99 - EXIT TO DIAGNOSTICS

MENU in the DIAGNOSTIC TEST MENU. Then in the DIAGNOSTICS MENU, select 9 -

EXIT TO MS-DOS.

Insert the Diagnostics disk for wireless LAN test into the Floppy Disk Drive. Turn on the power

while pressing U.

The following menu appears in the display.

************************************************************

* Intel Calexico2 11a/g Maintenance T&D Menu *

* *

* 1 : SKU check of Module *

* *

* 2 : MAC Address Check *

* *

* 3 : Antenna Check & communication test of 11b mode *

* *

* 4 : Communication test of 11a mode

* *

* 5 : Communication test of 11g mode

* *

* 6 : All the tests of Calexico2 11a/g Card *

* (SKU & MAC Check, 11a/b/g communication test) *

* *

************************************************************

SELECT TEST No, (1-6):

To execute the subtest, input the subtest number and press Enter.

Subtest01 SKU check of module

This subtest displays SKU information on the wireless LAN card installed. Selecting

this subtest, following message will appear in the display. Confirm if the right

information on the wireless LAN card is described.

*************************************************************

* *

* Module : Intel Calexico 802.11a/g (MoW) *

* G-code : xxxxxxxxxxxx *

* PBA No. : xxxxxx *
