ForThinkPadEdge15"andE50:
ForThinkPadEdge14"andE40:
Applyinglabelstothebasecover
ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveralkinds.
IftheWindowsCerticateofAuthenticationlabel(COA)
3isattachedtoapartthatisreplaced,returnthe
oldpartwiththelabelattachedtothecustomer,orprovidealettertothecustomerstatingwhatthelabel
wasoriginallyonthesystemandwhatthelabelpartnumber,serialnumber,andproductkeywere.
Whenyoureplacethebasecover,applythefollowinglabels:
4
Batterywordlabel
6
Homologationlabel
92HardwareMaintenanceManual
