ForThinkPadEdge14"andE40:
2b
2c
2a
2d
Note:Step3isonlyforThinkPadEdge15".ForThinkPadEdge14",skipstep3.
StepScrew(quantity)Color
Torque
3
M2×4mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
4
Wheninstalling:Beforeyouattachthefanassemblytothecomputer,applythermalgrease,atan
amountof0.2grams,onthepartsmarkedaasinthefollowinggures.Eithertoomuchortooless
applicationofgreasecancauseathermalproblemduetoimperfectcontactwithacomponent.Forthenew
microprocessorthermaldevice/fan,youneedtopeelthethinlmofffromtherubbersmarkedb.
64HardwareMaintenanceManual
