•“1020Opticaldriveortravelcover”onpage58
•“1030Thermalcover”onpage59
•“1060Fanassembly”onpage62
•“1090Palmrestassemblywithcables”onpage69
•“1130Keyboard”onpage75
Removalstepsofthekeyboardbezel
2
2
2
2
2
1
1
2
2
StepScrew(quantity)Color
Torque
1
M2.5×6.5mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(7)
Black0.181Nm
(1.85kgfcm)
4
5
6
3
3
78HardwareMaintenanceManual
