Removalstepsofthefanassembly
1
Wheninstalling:Makesurethatthefanconnectorisattachedrmlytothesystemboard.
Note:Loosenthescrews2ato2finorder,butdonotremovethem.Whenyouattachthefan,securethe
screwsinorder.
ForThinkpadEdge15"andE50:
3
2b
2c
2a
2d
2f
2e
Chapter8.RemovingorreplacingaFRU63
