StepScrew(quantity)Color
Torque
3
M2×3mm,small-head,nylon-coated(4)
Black0.181Nm
(1.85kgf-cm)
Wheninstalling:MakesurethattheLCDconnectorisattachedrmly.
2050Antennaassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1080WirelessWANslotcoverandPCIExpressMiniCardforwirelessWAN”onpage66
•“1090Palmrestassemblywithcables”onpage69
•“1100PCIExpressMiniCardforwirelessLAN”onpage72
•“1130Keyboard”onpage75
•“1140Keyboardbezel”onpage77
•“1150LCDunit”onpage79
•“2010LCDfrontbezel”onpage94
•“2020Speakerassembly”onpage95
•“2030Integratedcamera”onpage96
•“2040Hinges,LCDpanel,LCDcable,andLCDrearcoverassembly”onpage96
Chapter8.RemovingorreplacingaFRU99
