Steps5aareforThinkPadEdge14"andE40,andsteps5bareforThinkPadEdge15"andE50.
5b
5b
5a
5a
5b
5b
5a
5a
StepScrew(quantity)Color
Torque
5aor
5b
M2.5×6.5mm,wafer-head,nylon-coated(4)
Black0.392Nm
(4kgf-cm)
Chapter8.RemovingorreplacingaFRU81
