StepScrew(quantity)Color
Torque
3
M2×3mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
Wheninstalling:Makesurethattheconnectorsareattachedrmlytothesystemboard.
7
8
8
1150LCDunit
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1020Opticaldriveortravelcover”onpage58
•“1080WirelessWANslotcoverandPCIExpressMiniCardforwirelessWAN”onpage66
•“1090Palmrestassemblywithcables”onpage69
•“1100PCIExpressMiniCardforwirelessLAN”onpage72
•“1130Keyboard”onpage75
•“1140Keyboardbezel”onpage77
RemovalstepsoftheLCDunit
1
1
Chapter8.RemovingorreplacingaFRU79
- HardwareMaintenanceManual 1
