Chapter5.Statusindicators
Thischapterpresentsthesystemstatusindicatorsthatshowthestatusofthecomputer.
1
2
2
Table6.Statusindicators
IndicatorMeaning
1
Powerstatus
Green:
Theacadapterisconnected.Ifabattery
isinstalledonthecomputer,itischarged
whenthisindicatorison.
Off:
Theacadapterisnotconnected.
Sleep(standby)
status
2
Sleep(standby)
status
TheilluminationdotintheThinkPadlogoontheouterlidofthecomputerandonthe
palmrestworksasasystem-statusindicator:itshowswhetherthecomputerisinsleep
(standby),hibernation,ornormalmodel.
Red:
Thecomputerison(innormalmode).
Fastblinkingred:
Thecomputerisenteringsleep(standby)
orhibernationmode.
©CopyrightLenovo2010,2013
49
