Main code Sub code Content

66 None Simulation on the FAX panel (For details, refer to the FAX simulation.)

67 14 PCL PWB program download

Used to download the control program for PCL PWB.

(Operating procedure)

1. Download procedure

1) Enter the simulation code, and the Ready LED will light up and the On-line LED will go off.

2) Press the PRINT switch, and the Ready LED will go off and the Flash ROM data will be deleted.

3) After completion of deletion, the On-line LED lights up.

4) Get your PC into the DOS mode and execute "COPY /Bxxx.BIN LPT1", and downloading will be started and

the On-line LED will blink.

5) After completion of downloading, execute SUM check. If there is no problem, the On-line LED will go off and

the Ready LED will light up. If there is any problem, "F9-10:PCL PWB trouble" is displayed.

6) Turn OFF/ON the power.

2. In case of a fail in downloading, turn OFF/ON the power and perform procedure 1.

3. Items required for Flash downloading

1) PC

2) Parallel cable

3) Program data file

3. FAX simulations (AR-F152 only)

A. Entering the FAX simulation mode

There are following two ways of entering the Fax simulation mode. They differ only in the key sequence and the operations of the simulation are

the same in either mode.

For key operations in the FAX simulation mode, use the LCD display and the FAX panel.

During Fax operations, the Fax simulation cannot be entered.

(1) From the FAX panel

Procedure Procedure Position Operation

1 Press FUNCTION, 9, ∗, 8, #, 7. Fax Panel ROM version is displayed on the LCD.

2 Press ENTER. Fax Panel FAX enters the simulation mode.

The machine is in the normal display.

3 Press ← / → proper times. Fax Panel Each mode name is displayed on the LCD sequentially.

4 Press ENTER. Fax Panel The mode is determined.

5 Procedure in each mode Fax Panel Operations in each mode

Instead of above procedures 3 and 4, press the code (2 digits) of the target mode to enter the mode directly.

(2) From the COPIER panel

Procedure Procedure Position Operation

1 Press Clear, Exposure, Clear,

Exposure.

Copier Panel Waiting for simulation code.

FAX is in the normal display.

2 Enter the main code of 66 with

10Up/1Up keys.

Copier Panel “66” is displayed on 7SEG LED.

3 Press START key. Copier Panel The machine exits the simulation mode, and the FAX enters the

simulation mode.

4 Press ← / → proper times. Fax Panel Each mode name is displayed on the LCD sequentially.

5 Press ENTER. Fax Panel The mode is determined.

6 Procedure in each mode Fax Panel Operations in each mode

Instead of above procedures 4 and 5, press the code number (2 digits) of the target mode to enter the mode directly.

B. List of functions

Mode

Mode Details of functions

LCD display

(Mode name)

01 Soft switch setting

mode

This mode is used to change the soft switch setup. The available soft switches

are SW1 to SW30. The contents of soft switches are backed up.

For details of soft switches, refer to “Software Switch for FAX.”

01:SOFT SWITCH

02 Soft switch clear

mode (Only the

setup is cleared.)

This mode is used to reset the soft switch setup (including the user option setup)

to the default.

Since, however, some of soft switches have the adjustment values, the area for

the adjustment values is excluded from the targets.

02:SOFT SW CLEAR

AR-F152

9 – 14
