68
Stapling positions and stapling results
Saddle stitch function
To select saddle stitch, touch the [Saddle Stitch] key in the manual finishing screen.
Stapling positions
Stapling result
Vertically-oriented paper
Horizontally-oriented
paper
1 staple at top left corner
1 staple at bottom left corner
2 staples at left edge
Slant staple
Slant staple
Slanted stapling can be used when one staple at the top of the paper is selected
Saddle stitch
Result
Vertically-oriented paper Horizontally-oriented paper
