32

STAPLING OUTPUT/PUNCHING HOLES IN OUTPUT

Staple function

The staple function can be used to staple output.

This function saves considerable time when preparing handouts for a meeting or other stapled materials. The staple

function can also be used in combination with two-sided printing to create materials with a more sophisticated appearance.

Stapling positions and the number of staples can be selected to obtain the following stapling results.

*1 The staple orientation (" " or " ") varies depending on the size and orientation of the paper.

*2 Slanted stapling may not be possible for some paper sizes and orientations.

Punch function

The punch function can be selected to punch holes in printed output. Punch hole positions can be set by selecting the

binding edge.

An example of two-hole punching is shown below.

Staples Left Right Top

1 Staple*

1

1 Staple (Diagonal)*

2

2 Staples

Left Right Top

• To use the staple function, a finisher or saddle stitch finisher is required.

• To use the punch function, a punch module must be installed on the finisher or saddle stitch finisher.

• Paper that can be punched is 5-1/2" x 8-1/2" to 12" x 18" (16 lbs. to 90 lbs. Index) (B5R to A3 (52g/m

2

to 163g/m

2

)) when a

punch module of the finisher (for the MX-M850) and of the saddle stitch finisher is installed.

• For the maximum number of sheets that can be stapled, see "SPECIFICATIONS" in the Safety Guide.

The maximum number of sheets that can be stapled at once includes any covers and/or inserts that are inserted.

• The staple function cannot be used in combination with the offset function, which offsets the position of each output job

from the previous job.

• When the finisher is disabled in the machine's system settings (administrator), the staple function and punch function

cannot be used.

• When the staple function or the punch function is disabled in the machine's system settings (administrator), stapling or

punching is not possible.

• For information on the saddle stitch function, see "CREATING A PAMPHLET (Pamphlet/Pamphlet Staple)" (page 34).
