ORIGINAL SIZES
SPECIFYING THE ORIGINAL SIZE
When the original size is a non-standard size or is not detected correctly, manually specify the original size.
Touch the [Original] key in the base screen of copy mode and then follow the steps below.
Specifying an inch original size
Touch the appropriate original size key and then the [OK] key.
Specifying an AB original size
Touch the [AB Inch] key, touch the appropriate original size key, and then touch the [OK] key.
Specifying a non-standard original size
1
Touch the [Size Input] key.
5½x8½
5½x8½R
8½x11
8½x14
8½x13(216x330)
8½x13 (216x340)
8½x11R 11x17
Custom Size
Original
OK
Size Input
Inch
Auto
Manual
AB
Manual
(2)(1)
2
5
Original
OK
A5
A5R
B5
Size Input
A4R
A4
B5R B4
A3
Custom Size
Inch
Auto
Manual
AB
Manual
(3)(2) (1)
5½x8½
5½x8½R
8½x11
8½x14
8½x13(216x330)
8½x11R 11x17
Custom Size
Original
OK
Size Input
Inch
AB
8½x14
Auto
Manual
8½x13 (216x340)
2
5
