JOB QUEUE SCREEN AND COMPLETED JOB SCREEN
The job status screen consists of two screens: the job queue screen that shows reserved jobs and the job currently in
progress, and the completed jobs screen. To switch between the two screens, touch the job status screen selector key
((2) below).
Job queue screen Complete screen
(1) Mode switch tabs
Use these tabs to change the job status screen mode.
(2) Job status screen selector key
Touch this key to switch between the job queue screen
and the completed jobs screen.
(3) Job queue screen [Detail] key
This shows details on and the status of broadcast
transmission jobs that have been reserved or are in
progress. Select the key of the desired job in the job
queue screen (6) and then touch the [Detail] key.
CHECKING A RESERVED JOB OR THE JOB IN
PROGRESS (FAX MODE) (page 166)
(4) [Priority] key
Touch this key to give priority to a selected job.
GIVING PRIORITY TO A RESERVED JOB (page
169)
(5) [Stop/Delete] key
Touch this key to stop or delete a selected job.
CANCELING A JOB IN PROGRESS OR A
RESERVED JOB (page 168)
(6) Job queue screen
Jobs are shown as keys in the order they were reserved.
Each key shows information on the job and its current
status.
Job key display (page 163)
(7) Completed jobs screen [Detail] key
This shows detailed information on the results of
completed broadcast transmissions and jobs that used
the document filing function. Select the key of the desired
job in the completed jobs screen (9) and then touch the
[Detail] key.
From the details screen, it is possible to resend the fax to
destinations to which transmission was not successful.
CHECKING COMPLETED JOBS (page 167)
(8) [Call] key
Touch this key to call up and use a transmission or
reception job stored with the document filing function.
(9) Completed jobs screen
This shows up to 99 completed transmission or reception
jobs in each mode. A description of the job and the result
(status) are shown.
Jobs that used document filing function, broadcast
transmission jobs, and received Internet fax forwarding
jobs are indicated as keys.
Broadcast0001
1
2
3
4
10:00 04/04 020/003 Connecting
AAA AAA
BBB BBB
CCC CCC
10:05 04/04 000/001
Waiting
10:22 04/04 000/004
Waiting
10:30 04/04 000/010
Waiting
Broadcast0001
10:00 04/04 010/003 NG000000
Broadcast0002
Broadcast0003
DDD DDD
10:05 04/04 001/001
Send OK
10:22 04/04 004/004
Send OK
10:30 04/04 010/010
Send OK
Complete
Detail
Call
Job Queue
Print Job
Fax Job
Internet Fax
Scan to
Address Set Time
Pages
Status
1
1
Complete
Detail
Stop/Delete
Job Queue
Print Job
Fax Job
Internet Fax
Scan to
Address Start Time
Pages
Status
1
1
Priority
(1)
(1)
(6)
(9)
(2)
(3)
(4)
(5)
(2)
(7)
(8)
