MAKING COPIES USING THE BYPASS TRAY
In addition to plain paper, transparency film, and tab paper can be loaded in the bypass tray.
For detailed information on paper that can be loaded in the bypass tray, see the Safety Guide. For precautions when
loading paper in the bypass tray, see "LOADING PAPER IN THE BYPASS TRAY" in the User's Guide.
1
Place the original.
Place the original face up in the document feeder tray, or face
down on the document glass.
2
Place paper in the bypass tray.
Insert the paper with print side face up.
The procedure for loading paper varies depending on the
bypass tray installed. For the procedures for loading paper, see
"LOADING PAPER IN THE BYPASS TRAY" in the User's
Guide.
3
Touch the [Paper Select] key.
Special Modes
Plain
2-Sided Copy
Output
File
Quick File
Copy Ratio
1.
2.
7.
8½x11
8½x11
Original Paper Select
Auto
8½x11
Plain
Auto
8½x11
Exposure
Auto
8½x14
4.
11x17
11x17
6.
11x17
5.
11x17
3.
8½x11
100%
Plain
Plain
