54
FOLDING SPECIFIED PAPER IN HALF BEFORE
PRINTING (Paper Fold Print)
When a folding unit is installed, the paper can be folded
in half so that the printed output is half the paper size.
As an example, when the print data consists of mixed
letter (A4) and ledger (A3) sizes, ledger (A3) size can be
folded into letter (A4) size so that the actual width of all
pages of the printed output is letter (A4) width. The
folded paper can also be stapled (excluding sizes A4R,
Legal, and LetterR).
(1) Click the [Special Modes] tab.
(2) Click the [Fold Settings] button.
(3) Select the paper folding settings.
Select the checkbox of the paper size to be folded.
You can also click the [Select All] button to select all
paper sizes.
Mac OS X
(1) Select [Printer Features].
(2) Select [Paper Folding Settings].
(3) Select the paper folding settings.
Select the checkbox of the paper size to be folded.
Fold in Fold out
Windows
(1)
(2)
(3)
Macintosh
(3)
(1)
(2)
In Mac OS X v10.1.5, select the settings in "Paper
Folding Settings" on the [Advanced] tab of [Printer
Features].
