63
INSERTING INSERT SHEETS IN COPIES
(Insert Settings)
You can have different paper automatically inserted as inserts at specified pages of copies. Two types of paper can be
used as inserts, and the insertion positions can be specified separately for each.
Covers can be used in combination with inserts.
Example: Insert A after page 3 and insert B after page 5.
1
Insert the originals face up in the
document feeder tray.
Insert the originals all the way into the document feeder tray.
Multiple originals can be placed in the document feeder tray.
The stack of originals must not be higher than the indicator line
on the tray.
The document glass cannot be used.
2
Select the special modes.
(1) Touch the [Special Modes] key.
(2) Touch the [Covers/Inserts] key.
☞ SPECIAL MODES (page 43)
3
Touch the [Insertion Type A] key.
6
5
4
2 3 4 5 61
3
2
1
1
Originals
Copies
Insert A
Insert B
Indicator
line
Special Modes
OK
Cancel
OK
Front
Cover
Back
Cover
Insertion
Type B
Insertion
Type A
Insertion
Settings
Tray Settings
Inserts Setting
Cover Setting
Covers/Inserts
Page Layout
