Original Size Detector Setting
One of the five groups of standard original sizes shown below can be selected for detection by the original size detection
function.
Cancel Detection at Document Glass
Original size detection on the document glass can be disabled. When this is done, all originals placed on the document
glass are treated as special size originals.
Selections
Detectable original sizes
Document glass
Document feeder tray (automatic
document feeder)
AB-1
A3, A4, A4R, A5, B4, B5, B5R A3, A4, A4R, A5, B4, B5, B5R,
8-1/2" x 11", 8-1/2" x 14", 11" x 17"
AB-2
A3, A4, A4R, A5, B5, B5R,
216 mm x 330 mm (8-1/2" x 13")
A3, A4, A4R, A5, B4, B5, B5R,
8-1/2" x 11", 11" x 17"
216 mm x 330 mm (8-1/2" x 13")
AB-3
A4, A4R, A5, B4, 8K, 16K, 16KR A3, A4, A4R, A5, B4, 8K, 16K, 16KR,
8-1/2" x 11", 11" x 17"
216 mm x 330 mm (8-1/2" x 13")
INCH-1
11" x 17", 8-1/2" x 14", 8-1/2" x 11",
8-1/2" x 11"R, 5-1/2" x 8-1/2"
11" x 17", 8-1/2" x 14", 8-1/2" x 11",
8-1/2" x 11"R, 5-1/2" x 8-1/2", A4, A3
INCH-2
11" x 17", 8-1/2" x 13" (216 mm x 330 mm ),
8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2"
11" x 17", 8-1/2" x 13" (216 mm x 330 mm ),
8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2",
A4, A3
