PRINTER DRIVER SPECIFICATION LIST
7
PRINTER DRIVER
SPECIFICATIONS
Function PCL6 PCL5c PS
Windows
PPD
*1
Macintosh
PPD
*1
Frequently
used
functions
Copies 1-999 1-999 1-999 1-999 1-999
Orientation Yes Yes Yes Yes Yes
N-Up
Number
of
pages
2,4,6,8,9,16 2,4,6,8,9,16 2,4,6,8,9,16 2,4,6,9,16*
2,3
2,4,6,9,16
Order Selectable Selectable Selectable Selectable Selectable
Border On/Off On/Off On/Off Yes Selectable
2-Sided Print Yes Yes Yes Yes Yes
Fit To Page Yes Yes Yes No Yes*
4
Binding Edge Selectable Selectable Selectable No Yes*
5
Black and White
Print
Yes Yes Yes Yes Yes
Staple*
6
Yes Yes Yes Yes Yes
Punch*
6
Yes Yes Yes Yes Yes
Paper Paper Size Yes Yes Yes Yes Yes
Custom Paper 1 size 1 size 1 size Yes*
2
Yes*
5
Paper Selection Yes Yes Yes Yes Yes
Output tray Yes Yes Yes Yes Yes
Convenient
printer
functions
Pamphlet/Pamphlet
Staple*
7
Yes Yes Yes Yes Yes
Margin Shift 10mm/20mm/
30mm
10mm/20mm/
30mm
10mm/20mm/
30mm
Yes Yes
Poster Printing Yes No Yes No No
Rotate 180
degrees
Yes Yes Yes Yes Yes*
5
Zoom/XY-Zoom Yes*
8
Yes*
8
Yes Yes*
8
Yes*
8
Mirror Image No No Yes Yes Yes*
9
