31
Login by user number
Touch the [Admin Login] key.
Enter the administrator password in the administrator password
entry screen.
This completes the administrator login procedure. The system
settings (administrator) can be used.
• In addition to login by touching the [Admin Login] key, the system settings (administrator) can also be accessed when login
is performed by selecting a user with administrator rights from the user list or by entering a user number with administrator
rights. For more information on login procedures when user authentication is enabled, see "USER AUTHENTICATION" in
the User's Guide.
• To logout...
Press the [LOGOUT] ( ) key. (Except when entering a fax number.)
(If Auto Clear activates, logout will automatically take place.)
User Authentication
OK
Admin Login
