RELAY BROADCAST TRANSMISSION
USING F-CODES
When your machine receives an F-code relay request transmission, the fax is received to an F-code relay broadcast
memory box in your machine. Your machine then relays the fax to each of the end receiving machines programmed in
the memory box. Transmission to the end receiving machines takes place automatically.
• Prior to the operation, inform the requesting party of the sub-address and passcode of the relay broadcast memory box in
your machine.
• Program the end receiving machines in the F-code relay broadcast memory box when you create the box in your machine.
☞ CREATING MEMORY BOXES IN THE MACHINE FOR F-CODE COMMUNICATION (page 97)
• The end receiving machines do not need to support F-code communication.
• The machine that requests a relay broadcast transmission only bears the cost of sending the fax to your machine (the relay
machine). Your machine bears the cost of sending the fax to each of the end receiving machines.
The other
machine
Transmission
The fax is transmitted to
each of the end receiving
machines programmed in
the F-code relay
broadcast memory box.
The machine
F-code relay broadcast
memory box
Box name: BBBB
Sub-address: AAAAAAAA
Passcode: XXXXXXXX
Sub-address: AAAAAAAA
Passcode: XXXXXXXX
Transmission specifying an F-code
End receiving machines are
programmed in this box
End receiving
machines
