8
This chapter describes the system settings that can be configured by general users of the machine.
Accessing the System Settings (General)
Make sure that the machine is in the standby state and
then press the [SYSTEM SETTINGS] key on the
operation panel.
When the [SYSTEM SETTINGS] key is pressed, the
following menu screen appears on the touch panel.
Touch the item in this screen that you wish to configure.
For detailed explanations of each of the settings, see the
following pages of this chapter.
2
SYSTEM SETTINGS (GENERAL)
LOGOUT
LINE
PRINT
IMAGE SEND
DATA
DATA
READY
SYSTEM
SETTINGS
HOME
JOB STATUS
System Settings
Admin Password Exit
Total Count
Paper Tray
Settings
Printer Condition
Settings
Document Filing
Control
Address Control
Fax Data
Receive/Forward
USB-Device Check
Default Settings
List Print
(User)
• To quit the system settings, touch the [Exit] key in the top right corner of the screen.
• For the procedure to follow when user authentication is enabled, see "USER AUTHENTICATION" in the User's Guide.
