PLACEMENT ORIENTATION OF THE ORIGINAL

When an 8-1/2" x 11" (A4) original is placed in vertical orientation ( ), the image is automatically rotated 90 degrees

and transmitted in horizontal orientation ( ) (Rotation Sending). If the original is placed in horizontal orientation ( ), it

is transmitted in that orientation ( ) without being rotated.

AUTOMATIC REDUCTION OF THE TRANSMITTED


If the width of the transmitted image is larger than the width of the paper in the receiving machine, the image will be

automatically reduced to fit the receiving machine's paper width.

Example: Reduced sizes and reduction ratios

8-1/2" x 11"R and 5-1/2" x 8-1/2" (A4R, B5 and A5) size originals are not rotated for transmission.

System Settings (Administrator): Rotation Sending Setting

The factory default setting is rotate before transmission. If this setting is disabled, the original will be transmitted in the

orientation in which it is placed.

Transmitted image

width

Receiving machine's

paper width

Reduced size Ratio

A3 B4 B4 1 : 0.84

11" x 17" (A3)

8-1/2" x 14", 8-1/2" x 11" (A4)

8-1/2" x 14", 8-1/2" x 11"R (A4R)

1 : 0.71

B4 A4 A4R 1 : 0.84

System Settings (Administrator): Auto Reduction Sending Setting

The factory default setting is automatic reduction enabled. If this setting is disabled, the image will be sent at full size and part

of the image may be cut off.

Transmission

8-1/2" x 11"R (A4R)

image is transmitted.

Rotated to 8-1/2" x 11"R

(A4R) orientation

8-1/2" x 11"(A4)
