AR-651/810 TROUBLE SHOOTING 5 - 92

[Procedure 2]

Is the paper pushing plate home position sensor (PI14S) connected to the saddle stitcher controller

PC board?

Connect it to the board.

YES

Is the wiring between the sensor and the saddle stitcher correct?

YES

Correct the wiring.

Is 1 or 2V DC being supplied from J9-10 on the saddle stitcher controller PC board?

Replace the saddle stitcher controller PC board.

YES

Is J9-11 on the saddle stitcher controller PC board properly connected to the ground?

Replace the saddle stitcher controller PC board.

YES

END

[Procedure 3]

Is the paper pushing plate top position sensor (PI15S) connected to the saddle stitcher controller PC

board?

Connect it to the board.

YES

Is the wiring between the sensor and the saddle stitcher correct?

YES

Correct the wiring.

Is 1 or 2V DC being supplied from J9-13 on the saddle stitcher controller PC board?

Replace the saddle stitcher controller PC board.

YES

Is J9-14 on the saddle stitcher controller PC board properly connected to the ground?

Replace the saddle stitcher controller PC board.

YES

END

▼▼

▼
