5 - 91 AR-651/810 TROUBLE SHOOTING

[CBF] Abnormal saddle stitcher paper positioning plate motor

Is the paper positioning plate home position sensor (PI7S) working normally?

Replace the sensor.

YES

Is the paper positioning plate operating at the fixed timing?

YES

Replace the saddle stitcher controller PC board.

Is the paper positioning plate drive mechanism normal?

Fix the mechanism.

YES

Is the problem solved by replacing the paper positioning plate motor (M4S)?

Replace the saddle stitcher controller PC board.

YES

END

[CC0] Saddle stitcher sensor connector connection error

[Procedure 1]

Is the guide home position sensor (PI13S) connected to the saddle stitcher controller PC board?

Connect it to the board.

YES

Is the wiring between the sensor and the saddle stitcher correct?

YES

Correct the wiring.

Is 1 or 2V DC being supplied from J9-7 on the saddle stitcher controller PC board?

Replace the saddle stitcher controller PC board.

YES

Is J9-11 on the saddle stitcher controller PC board correctly connected to the ground?

Replace the saddle stitcher controller PC board.

YES

END
