AR-651/810 TROUBLE SHOOTING 5 - 34

[E76] Short-sized original exit jam

Are the registration roller, read roller, intermediate transport roller and small original reverse roller tainted?

Clean up the rollers.

Are the small original exit flapper and small original reverse flapper operating normally?

Adjust the small original exit solenoid.

[E77] Transport jam at scanning section

Are the registration sensor and read roller tainted?

Clean up the sensor and roller.

YES
