5 - 51 AR-651/810 TROUBLE SHOOTING

[EC2] Inserter reverse path delay jam 1

[EC3] Inserter reverse path stop jam 1

[EC4] Inserter reverse path delay jam 2

[EC5] Inserter reverse path stop jam 2

Are the transport roller and reverse roller tainted?

Clean up the rollers.

Is the harness between the inserter control board and reverse path sensor is open-circuited?

Replace the harness.

Is the reverse path sensor working improperly?

Replace the reverse path sensor.

Replace the inserter control board.

[EC6] Inserter transport delay jam 1

[EC7] Inserter transport stop jam 1

[EC8] Inserter transport delay jam 2

[EC9] Inserter transport stop jam 2

Is the transport roller tainted?

Clean up the roller.

Is the harness between the inserter control board and transport sensor is open-circuited?

Replace the harness.

Is the transport sensor working improperly?

Replace the transport sensor.

Replace the inserter control board.
