AR-651/810 TROUBLE SHOOTING 5 - 44

[EA8] Saddle stitcher stapling jam

Is there any paper remaining on the transport path in the finisher, saddle stitcher section or main

unit, or on the stapling tray?

YES

Remove the paper.

Is the jam cleared by taking off the staple cartridge from the finisher and removing the staples stuck

in the stapling unit?

YES

End

Is the connector J8 on the saddle stitcher controller PC board disconnected?

Is the harness connecting the saddle stitcher controller PC board and stitcher home position switch

(rear: MS5S, front: MS7S) open-circuited?

YES

Connect the connector securely. Replace the harness.

Are the stitcher home position switches working properly?

1. Connect the connectors of the stitcher home position switches securely.

2. Replace the stitcher home position switches.

YES

Replace the saddle stitcher controller PC board.
