ADVANCED TRANSMISSION METHODS

USING POLLING MEMORY

This function sends a document previously scanned into memory to a receiving machine when the receiving

machine calls and polls your machine. (If desired, you can restrict polling to fax machines whose fax number you

have programmed in your machine. See "Restricting polling access (polling security)" on page 43.) The machine has

"memory boxes", which are memory used for the regular polling memory function, F-code polling memory, F-code

confidential transmission, and F-code relay transmission (see "BOXES AND SUB-ADDRESSES/PASSCODES

REQUIRED FOR F-CODE TRANSMISSION" on page 50) The polling memory function explained here uses a

memory box called the "PUBLIC BOX".

Scanning a document into polling memory (the Public Box)

This section explains how to scan a document into the Public Box. If other documents have already been stored in

the Public Box, the new document will be appended to those documents. If the previous documents are no longer

needed, they can be replaced.

Follow steps 1 to 4 of "BASIC

PROCEDURE FOR SENDING FAXES"

(page 20) and then follow the steps

below.

Press the [SPECIAL FUNCTION] key.

Press the [SPECIAL

FUNCTION] key to display the

special function menu.

Select "ORIGINAL STORE" with the

[ ] or [ ] key.

Press the [OK] key.

Select "MEMORY POLLING" with the

[ ] or [ ] key.

Press the [OK] key.

• If there are no previously stored documents in the

Public Box, the above screen appears. If the above

screen appears, go to step 7.

• If there are previously

stored documents in the

Public Box, a screen will

appear to let you select

what action to take.

(1) If you wish to append the new document, select

"ADD" with the [ ] or [ ] key, press the [OK] key,

and then go to step 7.

(2) If you wish to replace the previous document with

the new document, select "CHANGE" with the [ ]

or [ ] key, press the [OK] key, and then go to step

When using the polling memory function, do not set the reception mode to MANUAL. (See "SETTING THE

RECEPTION MODE" on page 63.)

Note

DUPLEX

SPECIAL FUNCTION

ACC.

DUPLEX SCAN

PQR

DUPLEX

SPECIAL FUNCTION

DUPLEX SCAN

SPECIAL FUNCTION

COMM. SETTING

ORIGINAL STORE

GHI

BACK

SPECIAL FUNCTION

ORIGINAL STORE

ENTRY

SELECT READING

MEMORY POLLING

S.A.M-POLL ORIG

SELECT SENDING

1 TIME

REPEAT

ORIGINAL

ADD

CHANGE

DELETE

Pegasus-E_Fax_Sec.book 41 ページ２００４年９月２４日　金曜日　午後２時５１分
