34
3
ADVANCED TRANSMISSION
METHODS
This chapter explains advanced features that are designed for specific purposes and circumstances. Please read
those sections that are of interest to you.
SENDING THE SAME DOCUMENT TO
MULTIPLE DESTINATIONS IN A SINGLE
OPERATION
(BROADCAST TRANSMISSION)
This feature is used to send a fax to multiple destinations in a single operation. The original to be transmitted is
scanned into memory and then successively transmitted to the selected destinations. This feature is convenient for
such purposes as distributing a report to company branches. Up to 200 destinations can be selected. When
transmission to all destinations has been completed, the document is automatically cleared from memory.
• If you frequently use broadcasting to send faxes to the same group of destinations, it is convenient to program
those destinations into a group key. Group key dialing is an automatic dialing function whereby multiple
destinations (Rapid keys, Speed Dial numbers, and full fax numbers entered with the numeric keys) are
programmed into a Rapid key. The procedure for programming group keys is explained on page 64.
• When a group key is used to send a fax, the fax is broadcast (transmitted) to the destinations programmed in
the group key. For example, if five destinations are programmed in a group key and the key is pressed for a
broadcast transmission, the broadcast transmission will have five destinations.
Note
E
PAPER ZOOM
AUTO %
OUTPUT DUPLEX
E
M
RESOLUTION
RESOLUTION
ADDRESS FORMAT
ORIGINAL SIZE DUPLEX SCAN
DUPLEX SCAN
ORIGINAL SIZE
ADDRESS
BROADCAST
Beep
The document is scanned
into memory
Reception
Reception
Reception
Destination A
(recipient)
Successive
transmission
Beep
Beep
Destination B
(recipient)
Destination C
(recipient)
Sender
Select the broadcast
transmission function.
Pegasus-E_Fax_Sec.book 34 ページ ２００４年９月２４日 金曜日 午後２時５１分
