PG-A20X

AC socket

Rear adjustment

foot

(on the bottom of

the projector)

Intake vent

Kensington Security

Standard connector

INPUT 1 terminal

Terminal for

computer RGB and

component signals.

RS-232C terminal

For controlling

the projector using a

computer.

AUDIO INPUT

terminal

Shared audio input

terminal for INPUT

1, 2 and 3.

INPUT 2 terminal

Terminal for

connecting video

equipment with an

S-video terminal.

INPUT 3 terminal

Terminal for

connecting video

equipment.

Projector (Rear View)

Using the Kensington Lock

This projector has a

Kensington Security Stan-

dard connector for use with

a Kensington MicroSaver

Security System. Refer to

the information that came

with the system for instruc-

tions on how to use it to se-

cure the projector.
