4-78 Performing Setup from the Printing Unit Control Panel
Sharp AR-C360P EFI Configuration Guide - 78
9100-9103 (Port 9100)
Enabled/Disabled [Enabled]
Select Enable to enable the 9100-9103 (Port 9100) ports. (Port
9100 printing)
EFI Ports
Enabled/Disabled [Enabled]
Select Accept to enable EFI ports 8021-8022. (Fiery utilities and
printer driver Two-Way Communication feature)
Sharp Ports
Enabled/Disabled [Enabled]
Select Accept to enable Sharp ports. (Sharp utilities and printer
driver Two-Way Communication feature)
IPX/SPX Setup options
For protocols other than IPX/SPX, the frame type is automatically
enabled and does not require setup, as follows:
To specify the frame types the Fiery uses for IPX/SPX protocols, choose
IPX/SPX Setup from the Protocol Setup menu. You must choose at
least one frame type to enable IPX/SPX protocols. The Fiery supports
the following frame types for IPX/SPX:
• For Ethernet—Ethernet 802.2, Ethernet 802.3, Ethernet II,
and Ethernet SNAP
With this protocol
And these printing
services
This frame type is
automatically
enabled
AppleTalk PAP (Printer Access
Protocol)
Ethernet SNAP
TCP/IP with Ethernet LPD (Line Printer
Daemon)
Ethernet II
