4-59 Fiery Setup from the Printing Unit Control Panel
Sharp AR-C360P EFI Configuration Guide - 59
Setup is required the first time the machine is turned on after
installation or if the hard disk drive has just been replaced. In this
initial Setup, you (or the service technician) choose the language
for the Printing Unit Control Panel menus and messages. If you do
not configure a particular Setup option, the Fiery uses default
settings. Make sure the settings are appropriate for the printing
environment at your site.
Fiery Setup from the Printing Unit Control
Panel
Setup performed from the Control Panel configures the Fiery to
communicate with other devices and manage print jobs sent to it.
Setup provides these groups of options:
• Server Setup to specify system options
• Network Setup to specify all the active network systems that
transmit print jobs to the Fiery
• Parallel Setup to determine if and how the parallel port is used
• USB Setup to determine if and how the USB port is used
• Printer Setup to specify how print jobs and queues are managed
• PS Setup to specify PostScript settings
• PCL Setup to specify PCL settings
• Color Setup to specify color settings
• Job Log Setup to specify how the Fiery handles its log of printed
jobs
• PrintMe Setup to specify the PrintMe settings
• Custom Process to specify special custom color settings
• Change Password to create and change the administrator
password
C
h
apter 4:
Performing
Setup from
the Printing
Unit Control
Panel
