4-67 Network Setup options
Sharp AR-C360P EFI Configuration Guide - 67
For each item you enable, you are prompted to enter settings for
that item. Default values, where applicable, appear in this manual
with square brackets.
You should display and select options only for the network
systems that are currently used at your site. If your network
requirements change, you can change Network Setup at any time.
The available network types, and the Setup areas that pertain to
them, are summarized in the following table.
To access Network Setup options
1. Confirm that the network cable is connected to the Fiery.
During Network Setup, the Fiery queries the network for zones,
servers, and server-based queues. If you perform Network Setup
without a connected and functioning network, default settings are
used that may not meet your needs.
2. Choose Network Setup from the main Setup menu as described on
page 4-62.
For this Network or
Connection Type
Use this
Port Setup
Use this Protocol
Setup
Use this Service
Setup
AppleTalk over
Ethernet
Ethernet Setup AppleTalk Setup AppleTalk printing
(PAP) is enabled
automatically.
TCP/IP over Ethernet Ethernet Setup TCP/IP Setup: Ethernet
Setup
LPD Setup
Web Services Setup
Windows Setup
Port 9100 Setup
IPP Setup
IPX/SPX over Ethernet Ethernet Setup IPX/SPX Setup PServer Setup (NDS,
Bindery, or both)
Parallel Parallel Port
Setup
—
—
