A
A-164 Troubleshooting
Sharp AR-C360P EFI Configuration Guide - 164
In Network Setup, when you configure the IPX (Novell)
connection, the Fiery queries the network for Novell file servers
and trees, and attaches to them temporarily. If a guest login is
enabled, it is used. If not, you are prompted to log in from
Command WorkStation.
If the selected NetWare file server or tree does not have a guest
account, or if the guest account has expired or been disabled by
the NetWare supervisor, you are prompted to notify the IPX
(Novell) administrator. In that case, there are two options:
• Enable a guest account on the NetWare server or tree for the
purpose of setup.
Add Server, Enter Your
Login Name, Enter Your
File Server Password
(Network
Setup > Service
Setup > PServer
Setup > Bindery Setup)
No NetWare print
server found.
No print server was found when Fiery queried
the file server you selected.
You must configure a print server and a print
queue for every NetWare file server that will
handle Fiery print jobs (see page 2-36).
Any Bindery Setup
screen
Novell error code,
followed by a message.
Novell NetWare has reported an error.
Command WorkStation reports the error
number and displays a brief message.
For the most common errors (listed in the
following table), a screen is displayed that
allows you to retry the action that evoked the
error, such as adding a server. If that is
not possible, you are prompted to notify the
Novell administrator, who will need to
troubleshoot the network.
Consult NetWare Administrator
documentation for further explanation of
Novell error codes.
After this Setup
screen
This message Means
