116

Status Monitoring Tool

Setting the operation environment

Setadvancedsettingsforpanelstatusacquisition.

1. From the [Option] menu click [Operation environment].

The[Settingofoperationenvironment]dialogboxwillappear.

2. Set the options.

1) Checkthe“ResponseconﬁrmationofcontrollerPC

throughICMPECHOpacket”checkbox.(Compulsory)

 Thecheckboxcannotbecleared.

•Timeout(seconds)

Setsthetimeoutvalueforconﬁrmingaresponsefrom

thetargetPC.Valuesoffrom1-10secondscanbe

selected.

•Retrycount

Setsthenumberofretriespermittedwhenconﬁrming

aresponsefromthetargetPC.Valuesoffrom1-10

times can be selected.

 Ifthereisnoresponse,adelayof“timeoutvaluexnumberofretries”secondswilloccur.

2) “Acquisitionofdisplayingprograminformation”checkbox

 CheckthisboxtoacquireinformationaboutthecurrentlydisplayedprogramfromthetargetPC.

3) “AcquisitionofscreencapturedisplayingbycontrollerPC”checkbox

 CheckthisboxtoacquirethecurrentlydisplayedscreencapturefromthetargetPC.Theacquired

screen captures will be displayed as thumbnails.

 Itmaynotalwaysbepossibletoacquirescreencapturesofmovies.

4) “Statusacquisitionofpanel(PNseries)”checkbox

 CheckthisboxtoacquireinformationaboutthepanelfromthetargetPC.

 ThisfunctioncanbeusedonlywiththeSHARPLCDmonitor(PNseries).

5) “Acquisitionoflicenseinformation”checkbox

 CheckthecheckboxtoviewthelicensecodeandtheﬁleversionoftheSHARPDigitalSignage

Software viewer version.

6) “Autoacquisitionunderthefollowinginterval”checkbox

Checkthisboxtoautomaticallyacquirepanelstatusatregularintervals.

•Acquisitioninterval

Settheintervalatwhichyouwanttoobtainpanelstatus.Valuesof1-60minutescanbeset.

3. Click [OK].

Setting the operation environment
