109

Status Monitoring Tool

This function is only available with the Network Version.

TheStatusMonitoringToolallowsyoutocheckpanelstatusandcontroltargetPCpower.

The main Status Monitoring Tool window

●Launching Status Monitoring Tool

1. From the Windows Taskbar, click [Start], [All Programs], [SHARP Digital Signage Software], [Tools],

[Status Monitoring Tool].

“StatusMonitoringTool”willlaunch.

●The main Status Monitoring Tool window

1)Menus

2)Toolbar

3)Grouptree

4)Panellist

1) Menus

Menu options are as follows:

Menu option Description

Relevant

page

File Exit ExitsStatusMonitoringTool. -

Panel

Select all panels Selects all panels displayed in the panel list.

p.112

Select panels without

response

Selects all panels in the panel list that are not responding

(includingpanelsforwhichstatushasnotbeenacquired).

p.112

Select panels with

response

Selects all panels in the panel list that are responding.

p.112

Monitoring status
