Batch Page Numbering
61
2. Sending
Documents
Batch Page Numbering
You can change the page numbering of the transmitted document from
simple numbering ("P.01", "P.02", etc.) to batch numbering, which
means that a slash and the total number of pages being sent are added
after each page number (for example, "P. 01/05", "P.02/05", etc.). This
allows the receiver to check for missing pages.
1
Load the document(s).
SEND READY will appear in the
display.
2
Press the PAGE COUNTER key.
The display will show:
ENTER # OF PAGE(S)
ENTER # (01-99)
3
Enter the total number of pages (“01”
to “99”) by pressing the numeric
keys.
• If you are sending a cover sheet, do
not include it in the total number of
pages (the number will be adjusted
automatically).
0
8
Example: 8 pages
R
PAGE COUNTER
all-FO4700.book Page 61 Tuesday, November 28, 2000 2:07 PM
