Clearing Paper Jams
173
9. Trouble-
shooting
Clearing jammed printing paper
If the printing paper jams, PAPER JAM will appear in the display.
Follow the steps below to clear the jam.
1
Press the green release and open the
print compartment cover.
• Caution!
The fusing unit inside the print
compartment becomes very hot
during operation. Be careful not to
touch the inside of the compart-
ment.
2
If the jammed paper is visible in the
print compartment, pull it out.
• Make sure no torn pieces of paper
remain in the print compartment
and rollers.
or
all-FO4700.book Page 173 Tuesday, November 28, 2000 2:07 PM
