A Look at the Operation Panel
10
RESOLUTION
STANDARD
FINE
SUPER FINE
HALF TONE
LINE IN USE
CHANGEOVER
POWER SAVE
STATUS CHECK
1
4 5 8 9 106 7
2 3
Display
This displays messages and prompts during operation and
programming.
LINE IN USE light
This lights when the fax machine is using the telephone line.
STATUS CHECK light
This lights when a paper size error or paper jam occurs, or when the
print compartment cover is open. A message will appear in the display
to indicate the problem. (The indicator also lights steadily when the
received document tray is not properly installed.)
Service indicator
This lights when a problem occurs which must be fixed by a service
technician.
A Look at the Operation Panel
1
2
3
3
4
all-FO4700.book Page 10 Tuesday, November 28, 2000 2:07 PM
